Fasco D119 is a 3-speed shaded-pole fan and blower motor rated 1/11–1/25–1/70 HP at 115V, 60 Hz, 1500 RPM. Features open air-over enclosure, thermally protected windings, ball bearings, and 1/2" diameter shaft with flat. Ideal for HVAC/R applications requiring variable-speed operation.
Fasco D119 Fan Motor 1/11-1/25-1/70 HP 115V 3-Speed
Regal Rexnord - Fasco
$169.95
In Stock — 10+ available
Write a Review
Write a Review
Regal Rexnord - Fasco
Fasco D119 Fan Motor 1/11-1/25-1/70 HP 115V 3-Speed
- SKU:
- D119
Specifications
- Product Type:
- Fan and Blower Motor
- Subcategory:
- Multi-Speed Shaded Pole
- Application:
- Residential/Commercial
- System Type:
- Split System, Heat Pump, Package Unit, Air Handler, Furnace
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 2.9-1.5-1.0 A
- Horsepower:
- 1/11-1/25-1/70 HP
- RPM:
- 1500 RPM
- Speeds:
- 3
- Frame Size:
- 4.4 Frame
- Mounting Type:
- Extended Studs
- Temperature Range:
- 40°C Ambient
- Fuel Type:
- Electric
- A2L Refrigerant:
- Yes
- Material:
- Rolled Steel
- Motor Type:
- Shaded Pole
- Power (kW):
- 0.07 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Shaft Type:
- Flat
- Overall Length:
- 6.36"
- Frame Length:
- 3 3/8"
- Country of Origin:
- Mexico
- UPC:
- 815585028123
- Lifecycle Status:
- Active
