Multi-speed direct-drive blower motor for fan coil and air conditioning/heating units. 115V single-phase, 1550 RPM with selectable horsepower (1/10, 1/15, or 1/25 HP). OEM replacement for residential HVAC systems.
Fasco D236 Multi-Speed Fan Coil Motor 1/10-1/25 HP 115V
Regal Rexnord - Fasco
$181.95
In Stock — 10+ available
- SKU:
- D236
Specifications
- Product Type:
- Blower Motor
- Subcategory:
- Direct-Drive Fan Coil Motor
- Application:
- Residential
- System Type:
- Fan Coil, Air Handler, Heat Pump
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Horsepower:
- 1/10-1/15-1/25 HP
- RPM:
- 1550 RPM
- Speeds:
- 3
- Mounting Type:
- Direct Drive
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- Frame Size:
- 4.4 Frame
- Motor Type:
- Shaded Pole
- Power (kW):
- 0.07 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Flat
- Overall Length:
- 18 3/8"
- Certifications:
- UL Recognized, CSA, A2L Compliant
- Country of Origin:
- Mexico
- UPC:
- 815585029199
- Lifecycle Status:
- Active
