Resideo ZD8X6TZ 24V Rectangular Zone Damper 8x6 Inch

Resideo ZD8X6TZ 24V Rectangular Zone Damper 8x6 Inch

Resideo

$234.95

In Stock

Write a Review
SKU:
ZD8X6TZ
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $23.95 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — call (312) 564-5212 or email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Shipping details

Specifications

Product Type:
Zone Damper
Subcategory:
Rectangular Damper
Application:
Residential/Commercial
System Type:
Split System, Heat Pump, Furnace, Air Handler
Installation Type:
OEM Replacement
Voltage:
24V AC
Voltage Class:
Low Voltage
Mounting Type:
Multi-Poise (Any Orientation)
Pressure Rating:
1.0 in. WC
Material:
Extruded Aluminum
Control Type:
Low Voltage
The Resideo ZD8X6TZ is a 24V automatic rectangular zone damper for multizone forced-air HVAC systems. Features power-closed, spring-return-open design with fail-safe normally open state, 30-second closure and 10-second spring return. Parallel blade aluminum construction with <1% leakage at 0.5 in. WC. Compatible with Honeywell TrueZONE panels and other 24V zoning systems.
!
