Resideo ZD6X6TZ 24V Rectangular Damper 6x6 Inch

Resideo ZD6X6TZ 24V Rectangular Damper 6x6 Inch

Resideo

$228.95

In Stock

(No reviews yet) Write a Review
SKU:
ZD6X6TZ
Product Type:
Zone Damper
Subcategory:
Rectangular Damper
Application:
Residential/Commercial
System Type:
Split System, Heat Pump, Package Unit, Furnace, Air Handler
Installation Type:
OEM Replacement
Voltage:
24V AC
Voltage Class:
Low Voltage
Mounting Type:
Direct Drive
Temperature Range:
40–140°F
Pressure Rating:
1 in. WC
Material:
Extruded Aluminum
Control Type:
Non-Programmable
Adding to cart… The item has been added

Flat-rate shipping. The same price to anywhere in the 50 states.

Ships same or next business day · UPS Ground, typically 1–5 business days.

Shipping details

The Resideo ZD6X6TZ is a 24V AC power-close, spring-return rectangular damper designed for zone control in forced-air HVAC systems. Built with extruded aluminum frame and blades, it features a direct-drive actuator with 90° rotation, adjustable range stops, and LED status indication. Rated for up to 1 inch water column static pressure with less than 1% leakage at 0.5 inch WC. Ideal for residential and light commercial zoning applications.
!
