Regal Rexnord FX03BK002 General Purpose Motor 3 HP 56HC TEFC

Regal Rexnord - Marathon

$613.95

In Stock — 10+ available

Write a Review
SKU:
FX03BK002
Product Type:
General Purpose Motor
Subcategory:
AC Induction Motor
Application:
Commercial
System Type:
Package Unit, Rooftop Unit, Air Handler
Installation Type:
OEM Replacement
Voltage:
208-230/460V, 190/380V
Voltage Class:
Line Voltage
Phase:
Three Phase
Amperage:
8.2-7.6/3.8 A (60 Hz), 9/4.5 A (50 Hz)
Horsepower:
3 HP
RPM:
3450/2850 RPM
Speeds:
1
Frame Size:
56HC Frame
Mounting Type:
Bolt-on Base
Fuel Type:
Electric
Material:
Rolled Steel
Adding to cart… The item has been added

Shipping: $42.65 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — call (312) 564-5212 or email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Shipping details

Marathon FLEX-IN-1™ 3 HP general-purpose motor, 3-phase, 208-230/460V (60 Hz) or 190/380V (50 Hz), 3450/2850 RPM, 56HC frame, totally enclosed fan-cooled (TEFC). Inverter-duty capable with reversible rotation and configurable mounting (F1/F2/F3). UL Recognized, CSA and CE certified.
!
