Nidec XS1CA1JCR Explosion Proof Motor 1 HP 115/208-230V

Nidec-US Motors

$796.95

In Stock

Write a Review
SKU:
XS1CA1JCR
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $41.00 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Explosion Proof Motor
Application:
Industrial
Installation Type:
OEM Replacement
Voltage:
115/208-230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Horsepower:
1 HP
RPM:
3450 RPM
Speeds:
1
Frame Size:
56
Motor Type:
Capacitor Start
Power (kW):
0.8 kW
Service Factor:
1.0
KVA Code:
L
Locked Rotor Torque:
74.13 oz-ft
Breakdown Torque:
76.05 oz-ft
Ambient Temperature:
40°C
Start Capacitor:
380 MFD
Bearing Sizes:
shaft end 6203, opposite end 6205
Nidec-US Motors 1 HP explosion-proof motor rated for hazardous locations. Single-phase, TEFC enclosure, 3450 RPM. Dual voltage 115/208-230V operation. Designed for Class I, Division 1 or 2 environments where flammable gases or vapors may be present.
