Nidec US Motors HO60P2BLG Vertical Hollow Shaft Motor 60 HP

Nidec-US Motors

$7,430.95
Write a Review
SKU:
HO60P2BLG

Sold by freight quote

Tell us where it’s going and we’ll come back with a price and freight cost.

Request price & availability

We reply within one business day — quotes@globalpartsupply.com

Specifications

Product Type:
Vertical Hollow Shaft Motor
Subcategory:
High-Thrust Pump Motor
Application:
Commercial/Industrial
System Type:
Pump Drive, Turbine, Propeller Pump
Installation Type:
OEM Replacement
Voltage:
230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Horsepower:
60 HP
RPM:
1785 RPM
Speeds:
1
Frame Size:
364
Mounting Type:
P Base
Temperature Range:
40°C Ambient Maximum, 3,300 Feet Altitude
Fuel Type:
Electric
Motor Type:
Three Phase
Power (kW):
44.7 kW
Service Factor:
1.15
Service Factor Amps:
157/79A
KVA Code:
G
Locked Rotor Torque:
227% of full-load torque
Breakdown Torque:
250% of full-load torque
Ambient Temperature:
40°C
Bearing Sizes:
shaft end 6211-J
Nidec US Motors 60 HP three-phase vertical hollow shaft motor, 1785 RPM, 230/460V dual voltage. Weather Protected Type I (WPI) enclosure with premium efficient design and Class F insulation. Suitable for turbine, mix flow, and propeller pump applications with 1.15 service factor and special balance for high-thrust duty.
