Electronically commutated 1 HP HVAC motor with variable speed capability and auto-rotation sensing. Operates at 115/208-230V, 50/60 Hz with base speed of 1075 RPM and synchronous speed of 1200 RPM. Features 48Y frame, belly-band mounting, and open air-over enclosure. Suitable for furnace blowers, air handlers, and HVAC system applications.
Nidec-US Motors 5652 ECM Motor 1 HP 115/208-230V 1075 RPM
Nidec-US Motors
$271.95
Write a Review
Write a Review
Nidec-US Motors
Nidec-US Motors 5652 ECM Motor 1 HP 115/208-230V 1075 RPM
- SKU:
- 5652
Specifications
- Product Type:
- Electronically Commutated Motor (ECM)
- Subcategory:
- Blower Motor
- Application:
- Residential/Commercial
- System Type:
- Furnace, Air Handler, Heat Pump, Split System
- Installation Type:
- OEM Replacement
- Voltage:
- 115/208-230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 12.4/7.8-7.2 A
- Horsepower:
- 1 HP
- RPM:
- 1075 RPM
- Speeds:
- 1
- Frame Size:
- 48Y
- Mounting Type:
- Belly Band
- Fuel Type:
- Electric
- Motor Type:
- Brushless DC
- Power (kW):
- 0.8 kW
- Ambient Temperature:
- 40°C
- Bearings:
- Ball / Ball
