Nidec DJ5P2DP 5 HP Close Coupled Pump Motor 208-230/460V

Nidec-US Motors

$488.95

In Stock

Write a Review
SKU:
DJ5P2DP
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $86.00 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Close Coupled Pump Motor
Application:
Commercial
System Type:
Pump System
Installation Type:
OEM Replacement
Voltage:
208-230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Horsepower:
5 HP
RPM:
1755 RPM
Speeds:
1
Mounting Type:
Close Coupled
Fuel Type:
Electric
Frame Size:
184
Motor Type:
Three Phase
Power (kW):
3.7 kW
Service Factor:
1.15
KVA Code:
H
Locked Rotor Torque:
198% of full-load torque
Breakdown Torque:
305% of full-load torque
Ambient Temperature:
40°C
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6207-2Z-J/C3, opposite end 6206-2Z-J/C3
Shaft Type:
Single
C Dimension:
19"
Material:
Rolled Steel
Nidec-US Motors 5 HP close-coupled pump motor rated for 208-230/460V three-phase operation at 1755 RPM. ODP (Open Drip Proof) enclosure suitable for indoor pump applications. Direct-coupled design eliminates need for separate mounting and alignment.
