Nidec D30P2D general-purpose three-phase electric motor rated 30 HP at 1800 RPM. Designed for continuous duty in industrial and HVAC applications including pumps, fans, compressors, and material handling. Features NEMA 286T frame, ODP enclosure, Class F insulation, 1.15 service factor, and rigid base mount. Voltage: 208-230/460V; Amperage: 69.0/34.0 A.
Specifications
- Product Type:
- General Purpose Motor
- Subcategory:
- Three-Phase AC Motor
- Application:
- Industrial
- System Type:
- Pump, Fan, Compressor, Material Handling
- Installation Type:
- OEM Replacement
- Voltage:
- 208-230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Amperage:
- 69.0/34.0 A
- Horsepower:
- 30 HP
- RPM:
- 1780 RPM
- Speeds:
- 1
- Frame Size:
- 286
- Mounting Type:
- Rigid Base Mount
- Temperature Range:
- 40°C ambient maximum
- Fuel Type:
- Electric
- Material:
- Steel frame
- Motor Type:
- Three Phase
- Power (kW):
- 22.4 kW
- Service Factor:
- 1.15
- KVA Code:
- F
- Locked Rotor Torque:
- 194% of full-load torque
- Breakdown Torque:
- 256% of full-load torque
- Ambient Temperature:
- 40°C
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6310-2Z-J/C3, opposite end 6210-2Z-J/C3
- Shaft Type:
- Single
