Nidec 5480H Condenser Fan Motor 1/2 HP 460V

Name: Nidec 5480H Condenser Fan Motor 1/2 HP 460V
Brand: Nidec-US Motors
SKU: 5480H
Price: 297.95 USD
Availability: InStock

Nidec-US Motors

$297.95

In Stock

Write a Review

SKU:: 5480H
UPC:

in stock

Quantity:

Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $28.35 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — call (312) 564-5212 or request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Shipping details

Specifications

Product Type:: Condenser Fan Motor
Subcategory:: ECM Motor
Application:: Residential/Commercial
System Type:: Split System, Heat Pump, Package Unit
Installation Type:: OEM Replacement
Voltage:: 460V
Voltage Class:: Line Voltage
Phase:: Single Phase
Horsepower:: 1/2 HP
RPM:: 1075 RPM
Speeds:: 1
Frame Size:: 48 Frame
Mounting Type:: Belly Band

Description

Nidec-US Motors 5480H condenser fan motor for A/C and heat pump systems. 1/2 HP, 460V single-phase, 1075 RPM, TEAO enclosure, 48 frame. Reversible rotation with belly-band mounting for horizontal or shaft-down installation. Direct-drive replacement for standard induction motors.
