Nidec US Motors 1128 Condenser Fan Motor 1/2 HP 460V

Nidec-US Motors

$444.95

In Stock

Write a Review
SKU:
1128
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $28.81 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Condenser Fan Motor
Subcategory:
Single-Phase PSC Motor
Application:
Residential/Commercial
System Type:
Split System, Package Unit
Installation Type:
OEM Replacement
Voltage:
460V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
1.3A
Horsepower:
1/2 HP
RPM:
1075 RPM
Speeds:
1
MFD:
10 MFD 370V
Mounting Type:
Direct Drive
Fuel Type:
Electric
Connection Type:
Terminal Block
Frame Size:
48
Motor Type:
PSC
Power (kW):
0.4 kW
Service Factor:
1.0
Service Factor Amps:
1.3A
Locked Rotor Torque:
17.52 oz-ft
Breakdown Torque:
60.4 oz-ft
Ambient Temperature:
60°C
Bearing Sizes:
shaft end 6203, opposite end 6203
Single-phase, 460V, 1075 RPM with permanent split capacitor design and automatic overload protection. Open drip-proof enclosure rated for 40°C ambient. Includes ball bearings and vertical shaft orientation.
