Marathon X909 Motor 0.25 HP 115V 1725 RPM

Regal Rexnord - Marathon

$58.95

In Stock

Write a Review
SKU:
X909
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $23.95 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
General-Purpose Motor
Subcategory:
Single-Phase AC Motor
Application:
Residential/Commercial
Installation Type:
OEM Replacement
Voltage:
115V
Voltage Class:
Line Voltage
Phase:
Single Phase
Horsepower:
0.25 HP
RPM:
1725 RPM
Speeds:
1
Fuel Type:
Electric
Mounting Type:
Round - Extended Studs
Frame Size:
48Y Frame
Motor Type:
Split Phase
Power (kW):
0.19 kW
Service Factor:
1.0
KVA Code:
L
Power Factor:
74%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Nema 48
Overall Length:
7 5/8"
Frame Length:
4 3/8"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP43
Material:
Rolled Steel
Certifications:
UL Recognized, CSA
Country of Origin:
Mexico
UPC:
722856028556
Lifecycle Status:
Discontinued by manufacturer
Marathon 0.25 HP single-phase motor rated 115V, 1725 RPM. TEAO (Totally Enclosed Air Over) enclosure suitable for general-purpose HVAC and light industrial applications. Direct-drive compatible.
