1.5 HP three-phase motor rated 230/460V, 1800 RPM, designed for continuous duty on close-coupled pump applications. Features NEMA 145JMV frame with C-face, internal threaded 7/8" shaft, open drip-proof (ODP) enclosure, and rigid base mount. Service factor 1.15, Class F insulation, reversible rotation.
Marathon GT4104 Electric Motor 1.5 HP 230/460V
Regal Rexnord - Marathon
$386.95
In Stock — 10+ available
- SKU:
- GT4104
Specifications
- Product Type:
- Three-Phase Motor
- Subcategory:
- Pump Motor
- Application:
- Commercial
- System Type:
- Pump
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Amperage:
- 4.4/2.2 A
- Horsepower:
- 1.5 HP
- RPM:
- 1755 RPM
- Speeds:
- 1
- Frame Size:
- 145JMV Frame
- Mounting Type:
- Rigid Base Mount
- Fuel Type:
- Electric
- Connection Type:
- C-Face
- Material:
- Rolled Steel
- Motor Type:
- Three Phase
- Power (kW):
- 1.1 kW
- Service Factor:
- 1.15
- KVA Code:
- M
- NEMA Design:
- B
- Power Factor:
- 75%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Line Or Inverter
- Inverter Duty:
- Constant 2:1
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6206, opposite end 6203
- Shaft Type:
- JM
- Overall Length:
- 15.42"
- Frame Length:
- 9 1/16"
- Mounting Orientation:
- Horizontal Or Shaft Down
- Assembly Position:
- F1 Only
- IP Rating:
- IP22
- Country of Origin:
- Mexico
- UPC:
- 722856003294
- Lifecycle Status:
- Active
