Leeson 191547.00 Pedestal Fan Motor

Specifications

Product Type:

Pedestal Fan Motor

Voltage:

115/230V

Phase:

Single Phase

Horsepower:

0.5 HP

RPM:

1750 RPM

Speeds:

1

Frame Size:

48YZ Frame

Mounting Type:

Round - Extended Studs

Motor Type:

PSC

Power (kW):

0.37 kW

Service Factor:

1.0

KVA Code:

D

Power Factor:

97%

Duty:

Continuous

Ambient Temperature:

40°C

Starting Method:

Across The Line

Bearings:

Ball / Ball

Bearing Sizes:

shaft end 6203, opposite end 6203

Shaft Type:

Single Special Extension

Overall Length:

11.58"

Mounting Orientation:

Horizontal

Assembly Position:

F1 Only

IP Rating:

IP55

Material:

Stainless Steel

Certifications:

UL Recognized, CSA

Country of Origin:

China

UPC:

691720052563
