Leeson 1.5 HP single-phase close-coupled pump motor rated 115/230V, 1740 RPM with ODP enclosure and 145JM frame. Features capacitor-start induction-run design, 1.15 service factor, and rigid base for secure pump mounting.
Specifications
- Product Type:
- Close-Coupled Pump Motor
- Subcategory:
- Pump Motor
- Application:
- Residential/Commercial
- System Type:
- Pump
- Installation Type:
- OEM Replacement
- Voltage:
- 115/230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 17.2/8.6 A
- Horsepower:
- 1.5 HP
- RPM:
- 1740 RPM
- Speeds:
- 1
- Frame Size:
- 145JM Frame
- Mounting Type:
- Rigid Base
- Fuel Type:
- Electric
- Motor Type:
- Capacitor Start / Capacitor Run
- Power (kW):
- 1.1 kW
- Service Factor:
- 1.15
- KVA Code:
- J
- NEMA Design:
- L
- Power Factor:
- 73%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6206, opposite end 6203
- Shaft Type:
- JM
- Overall Length:
- 14.91"
- Frame Length:
- 7 1/2"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP22
- Material:
- Rolled Steel
- UPC:
- 691720016411
- Lifecycle Status:
- Active
