Leeson 2 HP three-phase electric motor rated for 460V, 3550 RPM operation. TEFC (totally enclosed fan-cooled) enclosure provides protection in demanding industrial and commercial HVAC applications. Suitable for compressors, fans, and pump drives.
Specifications
- Product Type:
- Three-Phase Electric Motor
- Subcategory:
- Industrial Duty Motor
- Application:
- Commercial/Industrial
- System Type:
- Compressor, Fan Drive, Pump Drive
- Installation Type:
- OEM Replacement
- Voltage:
- 460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 2 HP
- RPM:
- 3550 RPM
- Speeds:
- 1
- Fuel Type:
- Electric
- Mounting Type:
- Round
- Frame Size:
- 56J Frame
- Motor Type:
- Three Phase
- Power (kW):
- 1.5 kW
- Service Factor:
- 1.5
- KVA Code:
- S
- NEMA Design:
- B
- Power Factor:
- 76.5%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6205, opposite end 6203
- Shaft Type:
- Nema 56
- Overall Length:
- 15.93"
- Frame Length:
- 8 3/4"
- Mounting Orientation:
- Shaft Down
- Assembly Position:
- F1 Only
- IP Rating:
- IP43
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA
- Country of Origin:
- USA
- UPC:
- 691720053683
- Lifecycle Status:
- Active
