Fasco D1092 is a 1/3 HP, 115V two-speed OEM replacement motor designed for RV and mobile home air conditioning systems. Rated 1675/1080 RPM with 3.4A current draw, it features a 42-frame open-air-over enclosure, permanent split capacitor design (7.5 MFD 370V capacitor required, not included), and sleeve bearings.
Fasco D1092 Motor 1/3 HP 115V 1675/1080 RPM 2-Speed
Regal Rexnord - Fasco
$150.95
In Stock — 10+ available
- SKU:
- D1092
Specifications
- Product Type:
- OEM Replacement Motor
- Subcategory:
- Two-Speed Blower Motor
- Application:
- Residential
- System Type:
- RV Air Conditioning, Mobile Home HVAC
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 3.4A
- Horsepower:
- 1/3 HP
- RPM:
- 1675/1080 RPM
- Speeds:
- 2
- MFD:
- 7.5 MFD 370V
- Frame Size:
- 42 Frame
- Mounting Type:
- Stud Mount
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- A2L Refrigerant:
- Yes
- Motor Type:
- PSC
- Power (kW):
- 0.25 kW
- Service Factor:
- 1.0
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 7.5 MFD 370V
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Flat
- Overall Length:
- 15.02"
- Country of Origin:
- Mexico
- UPC:
- 815585028116
- Lifecycle Status:
- Discontinued by manufacturer
