Century T3102 Pool Pump Motor 1 HP 3-Phase 208-230/460V

Regal Rexnord - Century Motors

$356.95

In Stock — 10+ available

Write a Review
SKU:
T3102
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $30.00 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Pool Pump Motor
Subcategory:
Three-Phase Pump Motor
Application:
Residential/Commercial
System Type:
Pool Pump, Spa Pump
Installation Type:
OEM Replacement
Voltage:
208-230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Amperage:
3.2/1.6 A
Horsepower:
1 HP
RPM:
3450 RPM
Speeds:
1
Frame Size:
56J Frame
Mounting Type:
C-Face
Fuel Type:
Electric
Connection Type:
Threaded
Material:
Stainless Steel (shaft)
Motor Type:
Three Phase
Power (kW):
0.75 kW
Service Factor:
1.4
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Shaft Type:
7/16 Thread
Overall Length:
12.26"
Frame Length:
6 5/16"
Mounting Orientation:
Horizontal
Certifications:
CSA
Country of Origin:
Mexico
UPC:
786674032119
Lifecycle Status:
Active
Century T3102 is a 1 HP, 3-phase pool pump motor rated 208-230/460V, 3450 RPM with a 56J C-face frame and open drip-proof enclosure. Features sealed ball bearings, stainless steel threaded shaft, and internal junction box for direct pump mounting. CSA-certified for continuous duty.
