Century 1.5 HP single-phase pool pump motor with capacitor start-capacitor run design. Operates at 208-230/115V, 60 Hz, 3450 RPM with 56J frame and open drip-proof enclosure. Features sealed ball bearings, 303 stainless steel shaft, and automatic thermal protection.
Century ST1152 Pool Pump Motor 1.5 HP 208-230/115V
Regal Rexnord - Century Motors
$326.95
In Stock — 10+ available
- SKU:
- ST1152
Specifications
- Product Type:
- Pool Pump Motor
- Subcategory:
- Single-Speed Capacitor Start-Capacitor Run
- Application:
- Residential
- System Type:
- Pool Pump, Spa Pump
- Installation Type:
- OEM Replacement
- Voltage:
- 208-230/115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 10.4-9.8/19.6 A
- Horsepower:
- 1.5 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- 56J Frame
- Mounting Type:
- Round Flange
- Temperature Range:
- 50°C Ambient
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- Motor Type:
- Capacitor Start / Capacitor Run
- Power (kW):
- 1.1 kW
- Service Factor:
- 1.47
- Duty:
- Continuous
- Ambient Temperature:
- 50°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Shaft Type:
- 7/16 Thread
- Overall Length:
- 15 3/16"
- Frame Length:
- 9 1/4"
- Mounting Orientation:
- Horizontal
- Country of Origin:
- Thailand
- UPC:
- 786674031792
- Lifecycle Status:
- Discontinued by manufacturer
