Century FEH1026SF Condenser Fan Motor 1/4 HP 460V

Specifications

Product Type:

Condenser Fan Motor

Subcategory:

Single-Speed PSC Motor

Application:

Residential/Commercial

System Type:

Heat Pump, Refrigeration, Condenser Unit

Installation Type:

OEM Replacement

Voltage:

460V

Voltage Class:

Line Voltage

Phase:

Single Phase

Amperage:

1.0A

Horsepower:

1/4 HP

RPM:

1075 RPM

Speeds:

1

MFD:

7.5 MFD 370V

Frame Size:

48 Frame

Mounting Type:

Belly Band

Fuel Type:

Electric

A2L Refrigerant:

Yes

Material:

Rolled Steel

Motor Type:

PSC

Power (kW):

0.19 kW

Service Factor:

1.0

Duty:

Air Over

Ambient Temperature:

70°C

Starting Method:

Across The Line

Run Capacitor:

7.5 MFD 370V

Bearings:

Ball / Ball

Shaft Type:

Double Flat

Overall Length:

12 1/8"

Frame Length:

4 1/8"

Mounting Orientation:

Any

Assembly Position:

Any

UPC:

786674020949

Lifecycle Status:

Active
