Century 9434A Furnace Blower Motor 1/2 HP 277V 3-Speed
Regal Rexnord - Century Motors
$384.95
In Stock — 10+ available
- SKU:
- 9434A
Specifications
- Product Type:
- Motor
- Subcategory:
- Furnace Blower
- Application:
- Residential
- System Type:
- Furnace, Air Handler
- Installation Type:
- OEM Replacement
- Voltage:
- 277V
- Phase:
- Single Phase
- Amperage:
- 2.1A
- Horsepower:
- 1/2, 1/3, 1/4 HP
- RPM:
- 1075 RPM
- Speeds:
- 3
- MFD:
- 7.5 MFD 370V
- Frame Size:
- 48Y Frame
- Mounting Type:
- Torsion Flex Mount
- Material:
- Rolled Steel
- Motor Type:
- PSC
- Power (kW):
- 0.37 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 60°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 7.5 MFD 370V
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Flat
- Overall Length:
- 10.99"
- Frame Length:
- 4 7/8"
- Mounting Orientation:
- Any
- Country of Origin:
- India
- UPC:
- 786674011299
- Lifecycle Status:
- Active
- Assembly Position:
- Any
Direct-drive furnace blower motor with 1/2 HP, 277V, 1075 RPM, 3-speed operation. Features reversible rotation, sleeve bearings, and torsion flex mount for all-angle installation. Requires external 7.5 MFD 370V capacitor (not included).
