Two-way on-off zone valve for hydronic heating systems. 3/4" sweat connections, 24V AC actuator with normally closed operation and auxiliary N.O. end switch. Spring return to close with manual opener for power-failure operation. Rated 20 psi differential, 300 psi static, 50–200°F fluid temperature.
Resideo V8043E5012 Zone Valve 3/4" Sweat 24V N/C
Resideo
$129.95
In Stock
Write a Review
Write a Review
Resideo
Resideo V8043E5012 Zone Valve 3/4" Sweat 24V N/C
- SKU:
- V8043E5012
Specifications
- Product Type:
- Zone Valve
- Subcategory:
- Two-Way Spring Return
- Application:
- Residential/Commercial
- System Type:
- Boiler, Hydronic Heating, Radiant Floor
- Installation Type:
- OEM Replacement
- Voltage:
- 24V AC
- Voltage Class:
- Low Voltage
- Amperage:
- 0.32A
- Temperature Range:
- 50°F to 200°F
- Pressure Rating:
- 20 psi differential; 300 psi static
- Inlet Size:
- 3/4" Sweat
- Connection Type:
- Sweat/Solder
- Connection / Joint:
- Sweat/Solder
- Material:
- Brass body and seat, stainless steel stem, Buna-N rubber ball, EPDM packing
- Control Type:
- Low Voltage
- Switch Action:
- N.O. SPST
- Phase:
- Single Phase
- Ambient Temperature:
- 125°F
