Regal Rexnord SQ1032 Pool Pump Motor 1/3 HP 115/230V
Regal Rexnord - Century Motors
$229.95
In Stock — 10+ available
- SKU:
- SQ1032
Specifications
- Product Type:
- Pool Pump Motor
- Subcategory:
- Single-Phase Pump Motor
- Application:
- Residential
- System Type:
- Pool and Spa Pump
- Installation Type:
- OEM Replacement
- Voltage:
- 115/230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Horsepower:
- 1/3 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- 48Y Frame
- Mounting Type:
- Square Flange
- Fuel Type:
- Electric
- Motor Type:
- Capacitor Start
- Power (kW):
- 0.25 kW
- Service Factor:
- 1.95
- Duty:
- Continuous
- Ambient Temperature:
- 50°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Shaft Type:
- 1/2 Thread
- Overall Length:
- 11.82"
- Frame Length:
- 7 15/16"
- Mounting Orientation:
- Horizontal
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA
- Country of Origin:
- Mexico
- UPC:
- 786674031129
- Lifecycle Status:
- Active
Century Motors SQ1032 is a 1/3 HP single-phase pool and spa pump motor rated for 115/230V dual-voltage operation at 3450 RPM. Open drip-proof (ODP) enclosure design.
