Regal Rexnord H905 General Purpose Motor 1/2 HP 115V

Regal Rexnord - Marathon

$204.95

In Stock

Write a Review
SKU:
H905
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $26.70 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
General Purpose Motor
Application:
Residential/Commercial
Installation Type:
OEM Replacement
Voltage:
115V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
8.1A
Horsepower:
1/2 HP
RPM:
1725 RPM
Speeds:
1
Frame Size:
56Z Frame
Fuel Type:
Electric
Material:
Rolled Steel
Motor Type:
Split Phase
Power (kW):
0.37 kW
Service Factor:
1.15
KVA Code:
N
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Special Extension
Mounting Orientation:
Hor
Country of Origin:
Mexico
UPC:
722856006776
Lifecycle Status:
Active
Regal Rexnord - Marathon 1/2 HP general purpose motor, single-phase 115V 60Hz, 1725 RPM. Features 56Z frame, drip-proof enclosure, and permanently lubricated double-sealed bearings for extended service life. UL-recognized and CSA-certified for reliable performance in a variety of applications.
