The Regal Rexnord Fasco D354 is a multi-speed blower motor rated 115V, 1050 RPM, designed for HVAC air handler and fan coil applications. This motor powers blower wheels in split-system and packaged AC equipment to circulate air over coils. Features a 5-inch frame diameter with sleeve bearing construction and delivers consistent rotating power for reliable temperature control.
Regal Rexnord Fasco D354 Motor 1/6 HP 115V 1050 RPM
Regal Rexnord - Fasco
$421.95
In Stock — 10+ available
- Replaced by
- D354A
Write a Review
Write a Review
Regal Rexnord - Fasco
Regal Rexnord Fasco D354 Motor 1/6 HP 115V 1050 RPM
- SKU:
- D354
Specifications
- Product Type:
- Blower Motor
- Subcategory:
- Air Handler / Fan Coil
- Application:
- Residential/Commercial
- System Type:
- Split System, Package Unit, Air Handler, Fan Coil
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 3.1A
- Horsepower:
- 1/6-1/10-1/20 HP
- RPM:
- 1050 RPM
- Speeds:
- 3
- Frame Size:
- 42 Frame
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- Mounting Type:
- Resilient Rings
- Motor Type:
- PSC
- Power (kW):
- 0.13 kW
- Service Factor:
- 1.0
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 4 MFD 370V
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Flat
- Overall Length:
- 20.82"
- Certifications:
- UL Recognized, CSA, A2L Compliant
- Country of Origin:
- Mexico
- UPC:
- 815585029700
- Lifecycle Status:
- Discontinued by manufacturer
