Regal Rexnord F270 Ventilation Motor 1/8 HP 115V

Regal Rexnord - Century Motors

$335.95

In Stock — 10+ available

Write a Review
SKU:
F270
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $28.35 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Ventilation Motor
Application:
Residential/Commercial
System Type:
Furnace, Air Handler, Ventilation System
Installation Type:
OEM Replacement
Voltage:
115V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
3.0A
Horsepower:
1/8 HP
RPM:
1140 RPM
Speeds:
1
Frame Size:
J56CZ Frame
Fuel Type:
Electric
Mounting Type:
Round
Motor Type:
Split Phase
Power (kW):
0.1 kW
Service Factor:
1.4
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Shaft Type:
Keyed
Overall Length:
11 1/4"
Frame Length:
5 1/8"
Material:
Rolled Steel
Country of Origin:
Mexico
UPC:
786674019905
Lifecycle Status:
Active
Century 1/8 HP single-phase ventilation motor rated 115V, 1140 RPM with J56CZ frame and drip-proof enclosure. Thermally protected for continuous duty HVAC applications. Includes 2-1/4" x 5/8" shaft dimensions.
