Regal Rexnord EM3468F Condenser Fan Motor 1/2 HP 208-230V

Regal Rexnord - Century Motors

$113.95

In Stock — 10+ available

Write a Review
SKU:
EM3468F
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $27.25 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Condenser Fan Motor
Subcategory:
Multi-Horsepower TEAO
Application:
Residential/Commercial
System Type:
Split System, Package Unit, Rooftop Unit
Installation Type:
OEM Replacement
Voltage:
208-230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Horsepower:
1/2–1/4 HP
RPM:
1075 RPM
Speeds:
2
MFD:
12.5, 10 MFD
Frame Size:
48Y Frame
Mounting Type:
Flat
Fuel Type:
Electric
Motor Type:
PSC
Power (kW):
0.37 kW
Service Factor:
1.0
Duty:
Air Over
Ambient Temperature:
70°C
Starting Method:
Across The Line
Run Capacitor:
10 MFD 370V
Bearings:
Ball / Ball
Shaft Type:
Flat
Overall Length:
11.8"
Frame Length:
4 5/8"
Mounting Orientation:
Any
Material:
Rolled Steel
Certifications:
UL Recognized, CSA, A2L Certified
Country of Origin:
Mexico
UPC:
786674068996
Lifecycle Status:
Active
Century TEAO condenser fan motor rated 1/2 HP at 1075 RPM, 208-230V single-phase. Multi-horsepower design (1/2–1/4 HP selectable) with 2-speed capability and reversible rotation. 48 Frame, 1/2" shaft.
