FASCO 1/8 HP general-purpose fan and blower motor for HVAC/R applications. Single-phase, 115V, 3000 RPM with permanent split capacitor (PSC) design. Totally enclosed air-cooled enclosure with thermally protected Class B insulation. Includes 4 MFD 370V capacitor and 12" leads.
Regal Rexnord D219 Fan and Blower Motor 1/8 HP 115V
Regal Rexnord - Fasco
$298.95
In Stock — 10+ available
- SKU:
- D219
Specifications
- Product Type:
- Fan and Blower Motor
- Subcategory:
- General Purpose AC Motor
- Application:
- Residential/Commercial
- System Type:
- Split System, Package Unit, Air Handler, Furnace
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 1.8A
- Horsepower:
- 1/8 HP
- RPM:
- 3000 RPM
- Speeds:
- 1
- MFD:
- 4 MFD 370V
- Frame Size:
- 3.3 Frame
- Mounting Type:
- Extended Studs
- Fuel Type:
- Electric
- Motor Type:
- PSC
- Power (kW):
- 0.1 kW
- Service Factor:
- 1.0
- Duty:
- Continuous Air Over
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 4 MFD 370V
- Bearings:
- Ball / Ball
- Shaft Type:
- Flat
- Overall Length:
- 7.24"
- Frame Length:
- 4 15/16"
- Material:
- Steel
- Country of Origin:
- Mexico
- UPC:
- 815585029076
- Lifecycle Status:
- Active
