Century direct-drive fan and blower motor rated 1/3 HP at 115V, 1075 RPM single-speed operation. Open air-over enclosure design suitable for HVAC furnace blowers, air handlers, and fan coil applications. Reversible rotation with 1/2" shaft.
Regal Rexnord Century FDL1036 Fan Blower Motor 1/3 HP 115V
Regal Rexnord - Century Motors
$175.95
In Stock — 10+ available
- SKU:
- FDL1036
Specifications
- Product Type:
- Direct-Drive Blower Motor
- Subcategory:
- Furnace Blower
- Application:
- Residential/Commercial
- System Type:
- Furnace, Air Handler, Fan Coil
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 4.2A
- Horsepower:
- 1/3 HP
- RPM:
- 1075 RPM
- Speeds:
- 3
- Mounting Type:
- Direct Drive
- Fuel Type:
- Electric
- Frame Size:
- 48Y Frame
- Motor Type:
- PSC
- Power (kW):
- 0.25 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 50°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 7.5 MFD 370V
- Bearings:
- Ball / Ball
- Shaft Type:
- Flat
- Overall Length:
- 11.55"
- Frame Length:
- 4"
- Mounting Orientation:
- Horizontal
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA, A2L Compliant
- Country of Origin:
- India
- UPC:
- 786674020598
- Lifecycle Status:
- Active
