Regal Rexnord Century FB1156TE Condenser Fan Motor 1.5 HP

Regal Rexnord - Century Motors

$606.95
Write a Review
SKU:
FB1156TE

Currently out of stock

Tell us where it’s going and we’ll come back with a price and freight cost.

Request price & availability

We reply within one business day — quotes@globalpartsupply.com

Specifications

Product Type:
Condenser Fan Motor
Subcategory:
Direct Drive Fan Motor
Application:
Residential/Commercial
System Type:
Split System, Package Unit, Air Handler
Installation Type:
OEM Replacement
Voltage:
208-230/460V
Voltage Class:
Line Voltage
Phase:
Single Phase
Horsepower:
1.5 HP
RPM:
1075 RPM
Speeds:
1
Frame Size:
56Y Frame
Fuel Type:
Electric
Mounting Type:
Cushion Base
Motor Type:
PSC
Power (kW):
1.1 kW
Service Factor:
1.0
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Shaft Type:
Keyed
Overall Length:
18 1/16"
Frame Length:
8"
Material:
Rolled Steel
Certifications:
UL Recognized, CSA
Country of Origin:
Mexico
UPC:
786674020307
Lifecycle Status:
Active
Century condenser fan motor rated 1.5 HP, 1-phase, 208-230/460V, 1075 RPM. TEAO enclosure suitable for air handlers, blowers, and condenser fan applications in residential and commercial HVAC systems. Durable 56 Frame construction.
