Regal Rexnord C1460 Instant Reversing Motor 3/4 HP 115/230V

Regal Rexnord - Marathon

$622.95
Write a Review
SKU:
C1460

Currently out of stock

Tell us where it’s going and we’ll come back with a price and freight cost.

Request price & availability

We reply within one business day — quotes@globalpartsupply.com

Specifications

Product Type:
Instant Reversing Motor
Subcategory:
AC Induction Motor
Application:
Residential/Commercial
System Type:
Furnace, Air Handler, Package Unit
Installation Type:
OEM Replacement
Voltage:
115/230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
13.2/6.6 A
Horsepower:
3/4 HP
RPM:
1725 RPM
Speeds:
1
Frame Size:
56 Frame
Mounting Type:
Stud Mount
Fuel Type:
Electric
Motor Type:
Capacitor Start
Power (kW):
0.56 kW
Service Factor:
1.25
KVA Code:
M
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Nema 56
Mounting Orientation:
Any
Material:
Rolled Steel
Country of Origin:
Mexico
UPC:
722856042712
Lifecycle Status:
Active
Marathon instant reversing motor with electronic reverse switch for 1-phase 60 Hz applications. 3/4 HP, 1725 RPM, dual voltage 115/230V operation. 56 frame, drip-proof enclosure, continuous duty with 1.25 service factor. Includes thermal protection and extended clamp screws for belt guard mounting.
