The Regal GF2054 is a 1/2 HP split-phase motor rated for 115V single-phase operation at 1725 RPM. Designed for HVAC and general-purpose replacement applications, it features a 48 NEMA frame, open drip-proof enclosure, sleeve bearing construction, and reversible rotation capability. The motor draws 8.0 amps and includes a resilient base to minimize vibration.
Regal GF2054 1/2 HP Motor 115V 1725 RPM 48 Frame
Regal Rexnord - Century Motors
$194.95
In Stock — 10+ available
Write a Review
Write a Review
Regal Rexnord - Century Motors
Regal GF2054 1/2 HP Motor 115V 1725 RPM 48 Frame
- SKU:
- GF2054
Specifications
- Product Type:
- Split-Phase Motor
- Subcategory:
- General-Purpose / HVAC
- Application:
- Residential/Commercial
- System Type:
- HVAC, General-Purpose Equipment
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 8.0A
- Horsepower:
- 1/2 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Frame Size:
- 48 Frame
- Mounting Type:
- Resilient Base
- Material:
- Rolled Steel
- Motor Type:
- Split Phase
- Power (kW):
- 0.37 kW
- Service Factor:
- 1.25
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Keyed
- Overall Length:
- 8.9"
- Frame Length:
- 5 7/16"
- Certifications:
- CSA
- UPC:
- 786674021830
- Lifecycle Status:
- Discontinued by manufacturer
