Nidec US Motors PD6002 is a 1/4 HP belt-drive blower motor rated 115/208-230V, 1725 RPM, designed for residential and commercial HVAC air handling applications. Features a 48Z NEMA frame, reversible rotation, open dripproof enclosure, ball bearings, and resilient cradle base mount for vibration dampening. Field-reversible for clockwise or counter-clockwise operation.
Nidec-US Motors PD6002 Blower Motor 1/4 HP 115/208-230V
Nidec-US Motors
$150.95
In Stock — 10+ available
Write a Review
Write a Review
Nidec-US Motors
Nidec-US Motors PD6002 Blower Motor 1/4 HP 115/208-230V
- SKU:
- PD6002
Specifications
- Product Type:
- Belt Drive Blower Motor
- Subcategory:
- HVAC Furnace/Air Handler
- Application:
- Residential/Commercial
- System Type:
- Furnace, Air Handler, Package Unit
- Installation Type:
- OEM Replacement
- Voltage:
- 115/208-230V
- Phase:
- Single Phase
- Amperage:
- 5.2/2.5-2.6 A
- Horsepower:
- 1/4 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Frame Size:
- 48
- Mounting Type:
- Resilient Cradle Base
- Material:
- Rolled Steel
- Motor Type:
- Split Phase
- Power (kW):
- 0.2 kW
- Service Factor:
- 1.35
- KVA Code:
- P
- Locked Rotor Torque:
- 13.51 oz-ft
- Breakdown Torque:
- 37.59 oz-ft
- Ambient Temperature:
- 40°C
- Bearings:
- Ball
- Bearing Sizes:
- shaft end 6203, opposite end 6203
- Stack Length:
- 1 3/4"
