Nidec-US Motors D3P2AHZ Electric Motor 3 HP 1725 RPM

Specifications

Product Type:

Electric Motor

Subcategory:

General Purpose Motor

Application:

Industrial

System Type:

Furnace, Air Handler, Package Unit

Installation Type:

OEM Replacement

Voltage:

208-230/460V

Voltage Class:

Line Voltage

Phase:

Three Phase

Amperage:

9.7-9.4/4.6 A

Horsepower:

3 HP

RPM:

1725 RPM

Speeds:

1

Frame Size:

56

Mounting Type:

Rigid Base Mount

Fuel Type:

Electric

Material:

Rolled Steel Frame

Motor Type:

Three Phase

Power (kW):

2.2 kW

Service Factor:

1.15

Service Factor Amps:

10.3/5.1A

KVA Code:

K

Locked Rotor Torque:

380.6 oz-ft

Breakdown Torque:

585.5 oz-ft

Ambient Temperature:

40°C

Bearings:

Ball / Ball

Shaft Type:

Single

Stack Length:

4 1/4"
