Nidec US Motors 2 HP general-purpose three-phase motor rated for 1800 RPM at 200V. ODP (Open Dripproof) NEMA enclosure with Class F insulation and premium efficient IE3 performance. Suitable for pumps, fans, compressors, and material handling applications. 145T frame, 6.4 FLA.
Nidec US Motors D2P2H 2 HP Motor 1800 RPM 200V 3-Phase
Nidec-US Motors
$387.95
In Stock — 10+ available
- SKU:
- D2P2H
Specifications
- Product Type:
- General Purpose Motor
- Subcategory:
- Three-Phase AC Motor
- Application:
- Commercial/Industrial
- System Type:
- Pump, Fan, Compressor, Material Handling
- Installation Type:
- OEM Replacement
- Voltage:
- 200V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 2 HP
- RPM:
- 1740 RPM
- Speeds:
- 1
- Frame Size:
- 145
- Fuel Type:
- Electric
- Material:
- Cast Iron Frame, Aluminum End Shields
- Mounting Type:
- Horizontal / Footed
- Motor Type:
- Three Phase
- Power (kW):
- 1.5 kW
- Service Factor:
- 1.15
- Service Factor Amps:
- 7.1A
- KVA Code:
- L
- Locked Rotor Torque:
- 384% of full-load torque
- Breakdown Torque:
- 466% of full-load torque
- Ambient Temperature:
- 40°C
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6205-2Z-J/C3, opposite end 6203-2Z-J/C3
- Shaft Type:
- Single
