Nidec-US Motors 5462 Condenser Fan Motor 1/3 HP 1075 RPM

Nidec-US Motors

$132.95

In Stock — 10+ available

Write a Review
SKU:
5462
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $26.15 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Condenser Fan Motor
Subcategory:
PSC Blower Motor
Application:
Residential/Commercial
System Type:
Split System, Package Unit
Installation Type:
OEM Replacement
Voltage:
208-230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
2.6, 1.8 A
Horsepower:
1/3 HP
RPM:
1075 RPM
Speeds:
2
MFD:
5 MFD 370V
Frame Size:
48
Mounting Type:
Stud Mount
Fuel Type:
Electric
Material:
Rolled Steel
Motor Type:
PSC
Power (kW):
0.3 kW
KVA Code:
D
Locked Rotor Torque:
7.584 oz-ft
Breakdown Torque:
45.13 oz-ft
Ambient Temperature:
60°C
Bearings:
Ball / Ball
Nidec-US Motors 5462 is a 1/3 HP permanent split capacitor (PSC) condenser fan motor rated for 1075 RPM at 208-230V. Features reversible rotation, ball bearing construction, and multi-horsepower tap design (1/6–1/3 HP). Includes 48-inch leads, 1/2" shaft, and NEMA 48 frame. Requires 5 MFD 370V capacitor.
