Nidec-US Motors 1/3 HP general-purpose motor rated for 115V single-phase operation at 3450 RPM. TEFC (totally enclosed fan-cooled) enclosure provides protection in various environments. Suitable for replacement in HVAC blowers, pumps, and light industrial applications.
Specifications
- Product Type:
- General Purpose Motor
- Application:
- Residential/Commercial
- System Type:
- Furnace, Air Handler, Blower
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Horsepower:
- 1/3 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Fuel Type:
- Electric
- Frame Size:
- 48
- Motor Type:
- Split Phase
- Power (kW):
- 0.3 kW
- Service Factor:
- 1.0
- Service Factor Amps:
- 5.4A
- KVA Code:
- P
- Locked Rotor Torque:
- 15.55 oz-ft
- Breakdown Torque:
- 25.96 oz-ft
- Ambient Temperature:
- 40°C
- Bearings:
- Ball / Ball
