Nidec EB384 5 HP Air Compressor Motor 230V 56 Frame ODP

Nidec-US Motors

$393.95

In Stock — 10+ available

Write a Review
SKU:
EB384
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $45.40 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Air Compressor Motor
Subcategory:
Single-Phase Compressor Duty
Application:
Commercial/Industrial
System Type:
Air Compressor
Installation Type:
OEM Replacement
Voltage:
230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
21.5A
Horsepower:
5 HP
RPM:
3450 RPM
Speeds:
1
Frame Size:
56
Mounting Type:
Rigid Base Mount
Fuel Type:
Electric
Material:
Steel
Motor Type:
Capacitor Start
Power (kW):
3.7 kW
Service Factor:
1.15
Service Factor Amps:
24.4A
KVA Code:
L
Locked Rotor Torque:
209.2 oz-ft
Breakdown Torque:
344.3 oz-ft
Ambient Temperature:
40°C
Start Capacitor:
257 MFD
Bearing Sizes:
shaft end 6203, opposite end 6205
Nidec EB384 single-phase air compressor motor rated 5 HP at 3450 RPM base speed, 230V, 60 Hz. Open Drip-Proof (ODP) enclosure with 56 frame rigid base mount and Class F insulation. Delivers 120 ft-lbs torque with 1.15 service factor for reliable compressor duty operation.
