Nidec E177 Gear Reducer Motor 0.33 HP 3-Phase 1750 RPM

Nidec-US Motors

$289.95

In Stock

Write a Review
SKU:
E177
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $29.45 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Gear Reducer Motor
Application:
Commercial/Industrial
Installation Type:
OEM Replacement
Voltage:
208-230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Horsepower:
0.33 HP
RPM:
1750 RPM
Speeds:
1
Frame Size:
56
Mounting Type:
Extended Studs
Motor Type:
Three Phase
Power (kW):
0.2 kW
Service Factor:
1.25
KVA Code:
K
Locked Rotor Torque:
264% of full-load torque
Breakdown Torque:
375% of full-load torque
Ambient Temperature:
40°C
Bearings:
Ball / Ball
Shaft Type:
Single
Material:
Aluminum
Nidec-US Motors E177 gear reducer module motor delivers 0.33 HP at 1750 RPM for HVAC and industrial applications. Three-phase design rated 208-230/460V with TEAO enclosure for reliable operation in demanding environments.
