Nidec DJ7C1K21M Close-Coupled Pump Motor 7.5 HP 230V

Nidec-US Motors

$1,294.95
Write a Review
SKU:
DJ7C1K21M

Sold by freight quote

Tell us where it’s going and we’ll come back with a price and freight cost.

Request price & availability

We reply within one business day — quotes@globalpartsupply.com

Specifications

Product Type:
Close-Coupled Pump Motor
Subcategory:
Single-Phase Pump Motor
Application:
Residential/Commercial
System Type:
Pump System
Installation Type:
OEM Replacement
Voltage:
230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
31.4 A
Horsepower:
7.5 HP
RPM:
3480 RPM
Speeds:
1
Frame Size:
213
Mounting Type:
C-Face
Fuel Type:
Electric
Material:
Rolled Steel
Motor Type:
Capacitor Start
Power (kW):
5.6 kW
Service Factor:
1.15
KVA Code:
G
Ambient Temperature:
40°C
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6309-2Z-J/C3, opposite end 6205-2Z-J/C3
Shaft Type:
Single
Nidec DJ7C1K21M single-phase close-coupled pump motor, 7.5 HP, 3600 RPM, 230V. NEMA 213JM frame with ODP enclosure, reversible rotation, and C-face mounting for direct pump coupling. Ball bearings with locked shaft end construction and JM shaft for mechanical seal compatibility. Class F insulation, non-protected.
