Nidec-US Motors 2 HP three-phase general-purpose motor rated 208-230/460V, 3450 RPM, NEMA 56H frame with open drip-proof (ODP) enclosure. Suitable for HVAC air handlers, fans, blowers, and pump applications. Features ball bearings, reversible rotation, 1.15 service factor, and Class B insulation.
Specifications
- Product Type:
- Three-Phase General-Purpose Motor
- Subcategory:
- Industrial Induction Motor
- Application:
- Commercial
- System Type:
- Air Handler, Blower, Pump, Fan
- Installation Type:
- OEM Replacement
- Voltage:
- 208-230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Amperage:
- 5.4/2.7 A
- Horsepower:
- 2 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- 56
- Mounting Type:
- Rigid Base Mount
- Fuel Type:
- Electric
- Motor Type:
- Three Phase
- Power (kW):
- 1.5 kW
- Service Factor:
- 1.15
- Service Factor Amps:
- 5.8/2.9A
- KVA Code:
- J
- Locked Rotor Torque:
- 94.49 oz-ft
- Breakdown Torque:
- 171.4 oz-ft
- Ambient Temperature:
- 40°C
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6203, opposite end 6203
- Shaft Type:
- Single
- Stack Length:
- 2"
- Material:
- Rolled Steel
