Nidec-US Motors 15 HP three-phase general purpose motor rated for 200V operation at 1775 RPM. Open drip-proof (ODP) enclosure suitable for indoor, non-hazardous environments. Ideal for HVAC applications including large commercial air handlers, chillers, and rooftop units.
Specifications
- Product Type:
- General Purpose Motor
- Subcategory:
- Three-Phase Industrial Motor
- Application:
- Commercial
- System Type:
- Air Handler, Chiller, Rooftop Unit, Package Unit
- Installation Type:
- OEM Replacement
- Voltage:
- 200V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 15 HP
- RPM:
- 1775 RPM
- Speeds:
- 1
- Fuel Type:
- Electric
- Frame Size:
- 254
- Motor Type:
- Three Phase
- Power (kW):
- 11.2 kW
- Service Factor:
- 1.15
- Service Factor Amps:
- 48A
- KVA Code:
- G
- Locked Rotor Torque:
- 232% of full-load torque
- Breakdown Torque:
- 247% of full-load torque
- Ambient Temperature:
- 40°C
- Bearing Sizes:
- shaft end 6309-2Z-J/C3, opposite end 6309-2Z-J/C3
