Nidec D13P2AH General Purpose Motor 1/3 HP 3-Phase 1725 RPM

Nidec-US Motors

$225.95

In Stock — 10+ available

Write a Review
SKU:
D13P2AH
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $28.35 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
General Purpose Motor
Subcategory:
Three-Phase Industrial Motor
Application:
Commercial/Industrial
Installation Type:
OEM Replacement
Voltage:
208-230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Amperage:
1.4-1.4/0.7 A
Horsepower:
1/3 HP
RPM:
1725/1425 RPM
Speeds:
1
Frame Size:
56
Temperature Range:
104°F (40°C) Ambient
Motor Type:
Three Phase
Power (kW):
0.3 kW
Service Factor:
1.35
Service Factor Amps:
1.6/0.8A
KVA Code:
K
Locked Rotor Torque:
62.29 oz-ft
Breakdown Torque:
72.63 oz-ft
Ambient Temperature:
40°C
Bearing Sizes:
shaft end 6203, opposite end 6203
Nidec-US Motors 1/3 HP three-phase general-purpose motor rated for 208-230/460V at 1725 RPM. ODP (Open Drip-Proof) enclosure with 56H frame size. Premium efficient design suitable for industrial and commercial HVAC applications.
