Nidec 1826H Condenser Fan Motor 3/4 HP 208-230/460V 3-Phase

Nidec-US Motors

$479.95

In Stock

Write a Review
SKU:
1826H
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $35.23 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Condenser Fan Motor
Subcategory:
Three-Phase Commercial
Application:
Commercial
System Type:
Split System, Package Unit, Rooftop Unit
Installation Type:
OEM Replacement
Voltage:
208-230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Amperage:
2.8/1.4 A
Horsepower:
3/4 HP
RPM:
1140 RPM
Speeds:
1
Frame Size:
56
Mounting Type:
Rigid Base
Fuel Type:
Electric
Material:
Rolled Steel
Motor Type:
Three Phase
Power (kW):
0.6 kW
Service Factor:
1.0
KVA Code:
F
Locked Rotor Torque:
151.1 oz-ft
Breakdown Torque:
224.5 oz-ft
Ambient Temperature:
70°C
Bearings:
Ball / Ball
Nidec 1826H commercial condenser fan motor rated 3/4 HP at 1140 RPM, designed for higher-temperature HVAC applications. Features 208-230/460V 3-phase power, NEMA 56Z frame with rigid base mounting, ball bearings, and Class B insulation.
