Marathon 3 HP single-phase open drip-proof (ODP) motor rated for 230V operation at 3510 RPM. Designed for crop dryer applications and similar industrial duty cycles. OEM replacement or direct substitute for compatible agricultural equipment.
Marathon Z304 Crop Dryer Motor 3 HP 230V 3510 RPM
Regal Rexnord - Marathon
$580.95
In Stock — 10+ available
- SKU:
- Z304
Specifications
- Product Type:
- Agricultural Duty Motor
- Subcategory:
- Crop Dryer Motor
- Application:
- Industrial
- Installation Type:
- OEM Replacement
- Voltage:
- 230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Horsepower:
- 3 HP
- RPM:
- 3510 RPM
- Speeds:
- 1
- Mounting Type:
- Rigid Base
- Frame Size:
- 145TZ Frame
- Motor Type:
- Capacitor Start / Capacitor Run
- Power (kW):
- 2.2 kW
- Service Factor:
- 1.5
- KVA Code:
- E
- NEMA Design:
- L
- Power Factor:
- 97%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6205, opposite end 6203
- Shaft Type:
- Single Special Extension
- Overall Length:
- 13.74"
- Frame Length:
- 9 1/16"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP22
- Material:
- Rolled Steel
- Certifications:
- CSA
- Country of Origin:
- Mexico
- UPC:
- 722856028433
- Lifecycle Status:
- Active
