Marathon 10 HP variable-speed three-phase motor with TENV enclosure, rated for 230/460V operation at 1160 RPM. Designed for HVAC applications including fan drives, pump motors, and compressor duty. Regal Rexnord OEM part.
Marathon Y548 Variable Speed Motor 10 HP 3-Phase 230/460V
Regal Rexnord - Marathon
$3,193.95
- SKU:
- Y548
Specifications
- Product Type:
- Variable Speed Motor
- Subcategory:
- Three-Phase Industrial Motor
- Application:
- Commercial
- System Type:
- Package Unit, Rooftop Unit, Air Handler, Chiller
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 10 HP
- RPM:
- 1160 RPM
- Fuel Type:
- Electric
- Mounting Type:
- Rigid Base
- Speeds:
- 1
- Frame Size:
- 256TC Frame
- Power (kW):
- 7.5 kW
- Service Factor:
- 1.0
- KVA Code:
- J
- Power Factor:
- 75.5%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Inverter Only
- Inverter Duty:
- Constant 1000:1
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6309, opposite end 6206
- Overall Length:
- 26 7/8"
- Frame Length:
- 14 3/4"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1/F2 Capable
- IP Rating:
- IP43
- Material:
- Aluminum
- Certifications:
- UL Recognized, CSA, CE
- Country of Origin:
- USA
- UPC:
- 722856024848
