Marathon X000 Direct Drive Blower Motor 1/4 HP 115V

Regal Rexnord - Marathon

$135.95

In Stock — 10+ available

Write a Review
SKU:
X000
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $24.50 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Direct Drive Blower Motor
Subcategory:
Furnace/Air Handler Blower
Application:
Residential
System Type:
Furnace, Air Handler, Package Unit
Installation Type:
OEM Replacement
Voltage:
115V
Voltage Class:
Line Voltage
Phase:
Single Phase
Horsepower:
1/4 HP
RPM:
1075 RPM
Speeds:
3
Mounting Type:
Direct Drive
Frame Size:
48Y Frame
Motor Type:
PSC
Power (kW):
0.19 kW
Service Factor:
1.0
KVA Code:
C
Power Factor:
93%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Single Special Extension
Overall Length:
9 1/4"
Frame Length:
3 3/4"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP10
Material:
Rolled Steel
Certifications:
UL Recognized, CSA
Country of Origin:
Mexico
UPC:
722856038524
Lifecycle Status:
Active
Marathon 1/4 HP direct-drive blower motor for residential HVAC systems. Single-phase, 115V operation at 1075 RPM with open-air-over (OAO) enclosure. OEM replacement for furnaces, air handlers, and packaged units.
