Marathon 7.5 HP three-phase explosion-proof motor rated for hazardous locations. TEFC enclosure, 1765 RPM, dual voltage 230/460V operation. Designed for industrial applications requiring Class I or Class II area certification.
Marathon U006B Explosion Proof Motor 7.5 HP 230/460V
Regal Rexnord - Marathon
$1,523.95
Write a Review
Write a Review
Regal Rexnord - Marathon
Marathon U006B Explosion Proof Motor 7.5 HP 230/460V
- SKU:
- U006B
Specifications
- Product Type:
- Explosion Proof Motor
- Subcategory:
- Three-Phase Industrial
- Application:
- Industrial
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 7.5 HP
- RPM:
- 1765 RPM
- Speeds:
- 1
- Frame Size:
- 213T Frame
- Mounting Type:
- Rigid Base
- Power (kW):
- 5.6 kW
- Service Factor:
- 1.15
- KVA Code:
- H
- NEMA Design:
- B
- Power Factor:
- 79.2%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Line Or Inverter
- Inverter Duty:
- Constant 10:1
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6307, opposite end 6208
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP54
- Hazardous Location:
- Div 1 Exp Proof Cl I Gr Cd Cl Ii Gr Fg T3B
- Material:
- Cast Iron
- Certifications:
- CE
- Country of Origin:
- USA
- UPC:
- 722856066671
