Marathon general-purpose motor . 0.33 HP, single-phase, 1725 RPM, dual-voltage 115/230V operation. Open drip-proof (ODP) enclosure. Designed for energy-efficient, permanently lubricated operation with up to 70,000 hours continuous use.
Marathon S110 General Purpose Motor 0.33 HP 115/230V
Regal Rexnord - Marathon
$236.95
In Stock
- SKU:
- S110
Specifications
- Product Type:
- General Purpose Motor
- Subcategory:
- General Purpose Motor
- Application:
- Residential
- Installation Type:
- OEM Replacement
- Voltage:
- 115/230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Horsepower:
- 1/3 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Fuel Type:
- Electric
- Mounting Type:
- Resilient Base
- Frame Size:
- 48 Frame
- Motor Type:
- Capacitor Start
- Power (kW):
- 0.25 kW
- Service Factor:
- 1.0
- KVA Code:
- L
- Power Factor:
- 58.5%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6203, opposite end 6203
- Shaft Type:
- Nema 48
- Overall Length:
- 9 5/16"
- Frame Length:
- 3 3/4"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP22
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA
- Country of Origin:
- Mexico
- UPC:
- 722856007810
- Lifecycle Status:
- Active
